型號(hào)
Unit No. |
退卸套尺寸Dimentions of Sleeve |
參考Ret. |
退卸套重量
Weight of Sleeve
(kg) |
|
d1
mm |
Thread
MARK(D1)×Pitch |
L
mm |
L1
mm |
b
mm |
a
mm |
螺母型號(hào)
Unit No.of Nut |
軸承內(nèi)徑型號(hào)
Brg.lnner dia No. |
AHX3218
AHX3219
AHX3220
AHX3221
AHX3222
AHX3224
AHX3226
AHX3228
AHX3230
AH 3232
AH 3234
AH 3236
AH 3238
AH 3240
AH 3260
AH 3264
AH 3268
AH 3272
AH 3276
AH 3280
AH 3284
AHX3288
AHX3292
AHX3296
AHX32/500
|
85
90
95
100
105
115
125
135
165
150
160
170
180
190
280
300
320
340
360
380
400
420
440
460
480 |
M 100×2
105×2
110×2
M 115×2
125×2
135×2
M 165×2
155×3
165×3
M 180×3
190×3
200×3
TM210×4
220×4
TM330×5
350×5
TM370×5
400×5
420×5
TM440×5
460×5
480×5
TM510×6
530×6
550×6 |
63
67
73
78
82
90
98
104
116
124
134
160
165
153
228
246
264
274
284
302
321
330
349
364
393 |
67
71
77
82
86
94
102
109
119
130
160
166
152
160
236
254
273
283
294
312
331
341
360
376
405 |
10
11
11
11
11
13
15
15
17
20
24
24
25
25
34
36
38
40
42
44
46
48
50
52
54 |
13
16
16
16
16
16
18
18
20
23
27
27
31
31
40
42
44
46
48
50
52
54
56
58
60 |
AN 20
21
22
AN 23
25
27
AN 29
31
33
AN 36
38
40
HN 42
44
HN 66
70
HN 74
80
84
HN 88
92
96
HN 102
106
110 |
18
19
20
21
22
24
26
28
30
32
34
36
38
40
60
64
68
72
76
80
84
88
92
96
/500 |
0.576
0.680
0.767
0.890
1.04
1.30
1.60
1.90
2.30
4.09
4.81
5.31
5.90
6.67
26.0
30.6
65.8
41.6
46.3
52.5
59.7
64.8
75.2
83.1
94.7 |
